True STR1RPT-2HG-1S-HC Refrigerator, Pass-Thru - TRSTR1RPT2HG1SHC

True STR1RPT-2HG-1S-HC Refrigerator, Pass-Thru - TRSTR1RPT2HG1SHC

SPEC SERIES® Refrigerator, pass-thru, one-section, (2) glass half doors front, (1) stainless steel door rear, locks, cam-lift hinges, digital temperature control, (1) interior kit, LED interior lights, stainless steel front & sides, stainless steel interior, 5" castors, R290 Hydrocarbon refrigerant, 1/4 HP, 115v/60/1-ph, 3.8 amps, NEMA 5-15P, cULus, UL EPH Classified, Made in USA

What our Experts Think

• Dual-Sided Access: Equipped with two front glass half doors and one rear stainless steel door, this refrigerator allows efficient access from both kitchen and service areas, enhancing workflow and accessibility.

• Durable Construction: Constructed with a stainless steel front and sides, and an aluminum interior, it ensures durability and ease of maintenance, standing up to the demands of a commercial kitchen environment.

• Energy-Efficient Cooling: Utilizes R290 hydrocarbon refrigerant with a top-mounted compressor, promoting energy savings and environmental friendliness while maintaining optimal cooling performance.

• Precise Temperature Control: Maintains temperatures between 33°F and 38°F, suitable for various food storage needs, with an external digital display for easy monitoring.

• Enhanced Visibility: LED interior lighting illuminates the storage area, aiding in quick identification and organization of stored items.

• Mobility and Stability: Mounted on 5-inch casters for easy movement, with front set locking for stability during use, ensuring secure placement and flexibility in positioning.

• Comprehensive Warranty: Backed by a 7-year warranty on parts and labor, and a 7-year warranty on the compressor, reflecting True's commitment to quality and customer satisfaction.

Q&A

Q: What is the True STR1RPT-2HG-1S-HC Refrigerator?
The True STR1RPT-2HG-1S-HC is a one-section, pass-thru commercial refrigerator featuring two glass half doors on the front and one solid stainless steel door on the rear. Its pass-thru design allows for convenient access from both sides, making it ideal for high-traffic kitchen environments.

Q: What are its dimensions and capacity?
The refrigerator measures 27.5" in width, 36.13" in depth, and 77.75" in height, offering a storage capacity of approximately 31.0 cubic feet.

Q: What is the temperature range?
It maintains temperatures between 33°F and 38°F (0.5°C to 3.3°C), ensuring optimal preservation of perishable items.

Q: What type of doors does it have?
The unit features two glass half doors on the front and one solid stainless steel door on the rear, all equipped with locks and cam-lift hinges. The doors are self-closing with a 120° stay-open feature.

Q: What are the electrical requirements?
It operates on 115V/60Hz/1-phase power, drawing 3.8 amps, and comes with a NEMA 5-15P plug.

Q: Is it energy-efficient?
Yes, the refrigerator uses environmentally friendly R290 hydrocarbon refrigerant and features a top-mounted, self-contained refrigeration system for improved energy efficiency and durability.

Maintenance Tips

• Monthly Condenser Coil Cleaning: Disconnect the unit from power, remove the louver grill, and use a stiff bristle brush or vacuum to remove dust and debris from the condenser coils and surrounding area.

• Weekly Exterior Cleaning: Clean stainless steel surfaces with a soft cloth and non-abrasive, non-chloride cleaners. Avoid using steel wool or wire brushes. Rinse and dry thoroughly to prevent corrosion.

• Monthly Door Seal Inspection: Check the magnetic door gaskets for wear or damage. Clean them regularly and replace if necessary to ensure a proper seal and energy efficiency.

• Quarterly Interior Cleaning: Remove shelves and clean the interior surfaces, including side walls, back, floor, door liner, and ceiling, with a mild detergent. Rinse and dry thoroughly to maintain hygiene.

• Biannual Fan Motor Check: Inspect the electronically commutated condenser and evaporator fan motors for proper operation. Ensure the fan motor reverses direction upon compressor startup to clean the condensing coil.

• Annual Professional Servicing: Schedule a comprehensive inspection by a certified technician to assess electrical components, verify temperature accuracy, and ensure overall system performance.
