U.S. Motors FD1EA2D General Purpose Three Phase TEAO Rigid Motor - FD1EA2D

U.S. Motors FD1EA2D General Purpose Three Phase TEAO Rigid Motor - FD1EA2D

The U.S. Motors FD1EA2D is a general purpose three-phase TEAO rigid motor designed for various applications that demand reliability and performance. With a horsepower rating of one and operating at a speed of eighteen hundred revolutions per minute, this motor is well-suited for a range of industrial tasks.

Product Highlights

This motor features a rigid mount for stable installation and a sturdy design suitable for demanding operational conditions.

Features

• Voltage rating of 208-230/460 for versatile installation.
• Continuous duty operation to ensure high performance.
• TEAO enclosure providing excellent protection in varied environments.

Specifications

What our Experts Think

• Reliable and Efficient: The U.S. Motors FD1EA2D is a 1 HP, 1725 RPM motor designed for continuous-duty applications. Its three-phase TEAO (Totally Enclosed Air-Over) construction ensures consistent, efficient operation in demanding conditions.

• Built for Tough Environments: This motor is engineered for agricultural and industrial applications, offering durability and resilience in harsh settings, such as farms and factories.

• Long-Lasting Performance: Featuring a rigid base and automatic thermal overload protection, the FD1EA2D motor is built for long-term, hassle-free operation.

• Versatile Use: Its rugged design makes it ideal for fan, pump, and blower applications, particularly in settings where reliable and continuous performance is critical.

• Energy Efficient: The motor’s high efficiency and ability to operate in a variety of conditions make it an excellent choice for cost-conscious businesses looking for a dependable solution.

Q&A

Q: What is the U.S. Motors FD1EA2D motor?
A: The FD1EA2D is a 1 horsepower, 1725 RPM, three-phase electric motor designed for agricultural and industrial applications. It features a Totally Enclosed Air-Over (TEAO) enclosure and a rigid base mount, making it suitable for various fan and blower systems.

Q: What are the key specifications of the FD1EA2D motor?
A: This motor operates at 208-230/460V, 60Hz, with a 56H frame size. It includes Class F insulation, a service factor of 1.15, and is designed for continuous duty. The motor has a 5/8-inch diameter keyed shaft and is reversible.

Q: What is the weight of the FD1EA2D motor?
A: The motor weighs approximately 29 pounds, making it suitable for various installations.

Q: What are the applications of the FD1EA2D motor?
A: The FD1EA2D motor is ideal for use in agricultural fan systems, ventilation fans, and other machinery requiring reliable performance under variable load conditions.

Q: What is the product code for the FD1EA2D motor?
A: The product code is FD1EA2D.

Maintenance Tips

• Regular Inspection: Periodically check the motor for signs of wear, corrosion, or damage.

• Cleanliness: Keep the motor clean and free from dust and debris to prevent overheating.

• Lubrication: Ensure bearings are properly lubricated as per the manufacturer's recommendations.

• Cooling: Verify that the motor's cooling system is functioning correctly to maintain proper operating temperatures.

• Electrical Connections: Inspect electrical connections for tightness and signs of wear to prevent electrical faults.

• Vibration Monitoring: Monitor vibration levels to detect any imbalances or misalignments.

• Alignment: Ensure the motor is properly aligned with the driven equipment to prevent undue stress.

• Avoid Overloading: Ensure that the motor is not overloaded to prevent overheating or damage.
